UHF VHF Long Distance Portable Walkie Talkie

UHF Long Range Portable Two Way Radio

10W uhf 2800mAh Li-ion long range rugged handheld two way radio

Brand:
HYDX
Item NO.:
Q608
Order(MOQ):
200
Payment:
T/T,L/C,Credit Card,PayPal,Western Union,Cas
Product Origin:
China
Color:
Black
Shipping Port:
Xiamen/Shenzhen
Lead Time：
45~60
Weight：
280

Inquiry now

Product Detail

Product Description：

·As Juston's flagship product, Q608 is a walkie talkie with high power and high-capacity battery, business appearance and rich functions.

·High-power and high-gain antenna; Q608 two way radio has strong penetrability; can successive penetrate buildings; metal obstacles; ensure clear reception and transmission without distortion.
·16 Preset channels;non-standard CTCSS and DCS can minimize unnecessary chats from other channels.
·Rugged and durable body; dust-proof and drop-proof design; can withstand shock and vibration in harsh environments plus 2-meter drop.
·2800 mAh battery;fully charged can support about 18-21 hours of battery life; meet the needs of standard shifts; low battery alarm reminds you to charge it in time.
·Optional:waterproof shoulder microphone; can provide stable and reliable audio in bad weather; help work crews connect; coordinate and collaborate to get the job done right.

Main Functions

1.VOX

2.SOS

3.Scan

4.1750Hz

5.Scrambler

6.Compandor

7.Battery Save

8.Tail Elimination

9.Battery Report

10.High/ Low Power

11.PC Programmable

12.Wide/Narrow Band

13.SK Programmable

14.Chinese/English Voice Report

15.CTCSS/DCS Support Non-standard

Technical Specification

GENERAL
Frequency Range	UHF:400-470MHz VHF:136-174MHz
RF Output Power	H:10W±1W L:5W±0.5W
Channels	16
Channel Spacing	Wide:25KHz Narrow:12.5KHz
CTCSS/DCS	50 CTCSS / 105 DCS
Antenna Impedence	50Ω
Operating Temperature	-20℃+50℃
Operating Voltage	DC 7.4V
Battery Type	2800mAh
Dimension(Excluding antenna)	132(H)×61(W)×43(D)mm
Weight(Battery,Antenna Including)	About 280g
TRANSMITTER
Output Power	H:10W±1W L:5W±0.5W
Modulation	F3E
Modulation Sensitivity	12±5 mV
Adjacent Channel Power	≤-65 dB(Wide) ≤-55 dB(Narrow)
Modulation Distortion	≤5%
Transmit Spurious Emission	≤-65 dB
RECEIVER
Reference Sensitivity	≤-122 dBm
Adjacent Channel Selectivity	≥65 dB
Inter-modulation	-55 dB
S/N	≥50 dB (Wide) ≤-40 dB (Narrow)
Rated Output Power	≤1W
Rated Audio Distortion	≤5%
