High Power Long Range Two Way Radios

10W clearly voice multi-functions 10W handheld walkie talkie

Brand:
HYDX
Item NO.:
Q630
Order(MOQ):
200
Payment:
T/T,L/C,Credit Card,PayPal,Western Union,Cas
Product Origin:
China
Color:
Black
Shipping Port:
Xiamen/Shenzhen
Lead Time：
45~60
Weight：
280

Inquiry now

Product Detail

Product Description：

·The Q630 has a variety of housing options and strong endurance.It has high-quality sound and 16Ω speaker.Recommended places of use：hotel、restaurant、building、school，etc.

·High power dual band(VHF /UHF) radio, 16 Channels, Programming ham radio.

·Antenna provides a long distance to communicate , the strong penetration that ensure a clear calls in cities, obstacles, mountains.

·To provide a high quality sound even in noisy environments, ensure you definitely get clear transmit and receive audio.

·If you have any questions, please feel free to contact us and we will try our best to solve them.

Main Functions

1.136-174MHz/400-470MHz

2.High/Low Power Switchable 10W/5W

3.High Battery Capacity 2200mAh

4.Monitor

5.Tail Elimination

6.VOX

7.Power Save

8.Channel Scanning

Technical Specification

GENERAL
Frequency Range	UHF:400-470MHz VHF:136-174MHz
RF Output Power	H:10W±1W L:5W±0.5W
Channels	16
Channel Spacing	Wide:25KHz Narrow:12.5KHz
CTCSS/DCS	50 CTCSS / 105 DCS
Antenna Impedence	50Ω
Operating Temperature	-20℃+60℃
Operating Voltage	DC 7.4V
Battery Type	2200mAh
Dimension(Excluding antenna)	132(H)×62(W)×35(D)mm
Weight(Battery,Antenna Including)	About 280g
TRANSMITTER
Output Power	H:10W±1W L:5W±0.5W
Frequency Stability	±1.5×10-6ppm
Modulation Mode	F3E
Modulation Sensitivity	12±5 mV
Adjacent Channel Power	≥65 dB
Modulation Distortion	≤1%
Transmit Spurious Emission	≥62 dB
RECEIVER
Reference Sensitivity	≤122 dBm
Adjacent Channel Selectivity	≥55 dB
Inter-modulation response immunity	≥55 dB
Block	≥84 dB
Rated Output Power	≤1000mW @16Ω
Rated Audio Distortion	≤5%
