High Power Outdoor Long Distance Communication Devices

10miles UHF Long Range Portable Two Way Radios

Hot selling 10W handheld 3-10miles communication distance walkie talkie

Brand:
HYDX
Item NO.:
Q610
Order(MOQ):
200
Payment:
T/T,L/C,Credit Card,PayPal,Western Union,Cas
Product Origin:
China
Color:
Black
Shipping Port:
Xiamen/Shenzhen
Lead Time：
45~60
Weight：
280

Inquiry now

Product Detail

10miles Long Range Portable Two Way Radios

Product Description：

·Strong shell and stubborn accessories will last long time and save cost for your business.
·2200 mAh battery will last about 18-24 hours using;power your working time all the time.
·Belt clip and VOX function will offer real hands free;improve your working efficiency.
·Equipped with 6 way gang charger and charging 6 pack walkie talkies together to save time for your business.
·Emergency alarm will protect your safety when you work alone.

Main Functions

1.136-174MHz/400-470MHz

2.High/Low Power Switchable 10W/5W

3.High Battery Capacity 2200mAh

4.Monitor

5.Tail Elimination

6.VOX

7.Power Save

8.Channel Scanning

Technical Specification

GENERAL
Frequency Range	UHF:400-470MHz VHF:136-174MHz
RF Output Power	H:10W±1W L:5W±0.5W
Channels	16
Channel Spacing	Wide:25KHz Narrow:12.5KHz
CTCSS/DCS	50 CTCSS / 105 DCS
Antenna Impedence	50Ω
Operating Temperature	-20℃+60℃
Operating Voltage	DC 7.4V
Battery Type	2200mAh
Dimension(Excluding antenna)	132(H)×62(W)×35(D)mm
Weight(Battery,Antenna Including)	About 280g
TRANSMITTER
Output Power	H:10W±1W L:5W±0.5W
Frequency Stability	±1.5×10-6ppm
Modulation Mode	F3E
Modulation Sensitivity	12±5 mV
Adjacent Channel Power	≥65 dB
Modulation Distortion	≤1%
Transmit Spurious Emission	≥62 dB
RECEIVER
Reference Sensitivity	≤-122 dBm
Adjacent Channel Selectivity	≥55 dB
Inter-modulation response immunity	≥55 dB
Block	≥84 dB
Rated Output Power	≤1000mW @16Ω
Rated Audio Distortion	≤5%
