Digital UHF Handheld Police dPMR Radio

Commercial dPMR uhf or vhf digital radio

Brand:
HYDX
Item NO.:
D808
Order(MOQ):
500
Payment:
T/T,L/C,Credit Card,PayPal,Western Union,Cas
Product Origin:
China
Color:
Black
Shipping Port:
Xiamen/Shenzhen
Lead Time：
70~90days
Weight：
230

Inquiry now

Product Detail

Product Description：

·DMR uses 2-slot TDMA to achieve two communication paths per 12.5kHz channel, whereas dPMR uses FDMA to divide the 12.5kHz channel in to two 6.25kHz sub-channels.

·Dual band UHF/VHF radio on DMR and analog so you can have one radio for anything on the tech bands.

·Large battery capacity; 1600mAh battery enable normal use 2-3 days standby; 10-18 hours typical use; continues use 5-7 hours

·It can be applied to industry, commerce, public and other fields

Main Functions

1.400-480/450-520/136-174MHz

2.Support Digital/Analog Mode

3.Digital Voice Encryption

4.Private/Group/All Call

5.Kill/Activate

6.Power Save Function

7.High/Low Power Switchable

8.CTCSS/DCS

9.Tail Elimination

10.Monitor

11.Time-Out Time

Technical Specification

GENERAL
Frequency Range	UHF:400-480/450-520MHz VHF:136-174MHz
RF Output Power	H:≤5W L:≤1W
Channels	2*32
Modulation Distortion	≤5%
Channel Spacing	12.5KHz
Antenna Impedence	50Ω
Operating Temperature	-20℃+50℃
Operating Voltage	DC 7.4V
Battery Type	1600mAh
Dimension(Excluding antenna)	118(H)×58(W)×38(D)mm
Weight(Battery,Antenna Including)	About 230g
TRANSMITTER
Output Power	H:≤5W L:≤1W
Analog Modulation	11K&F3E@12.5KHz
Digital Modulation	8K30F1E@12.5KHz
Digital Audio En/Decode	ASELP/DVSI+2C
Spurious Radiation	9KHz-1GHz ≤-36dBm 1GHz-12.75GHz ≤-30dBm
Adjacent Channel Power	≤ -60 dB@12.5KHz
RECEIVER
Reference Sensitivity	≤ -120 dBm@12.5K
Adjacent Channel Selectivity	≥ 60 dB
Inter-modulation	≥ 60 dB
Co-channel Rejection	≥ -12 dB
Rated Output Power	≤1000mW @16Ω
Spurious Radiation	9KHz-1GHz≤-57dBm 1GHz-12.75GHz≤-47dBm
