5W dPMR Digital Private Mobile Radio

UHF VHF Long range 1600mAh battery dPMR digital private mobile radio

Brand:
HYDX
Item NO.:
D818
Order(MOQ):
500
Payment:
T/T,L/C,Credit Card,PayPal,Western Union,Cas
Product Origin:
China
Color:
Black
Shipping Port:
Xiamen/Shenzhen
Lead Time：
70~90days
Weight：
240

Inquiry now

Product Detail

5W dPMR Digital Private Mobile Radio

Product Description：

·As an economical dpmr digital walkie talkie, d818 can support digital mode and analog mode, and make the transmission of call information more secure through digital voice encryption.

·Support a variety of call functions，SMS functions，you can use it in public security, warehouses, buildings and other places.

·Large battery capacity; 1600mAh battery enable normal use 2-3 days standby; 10-18 hours typical use; continues use 5-7 hours.

·Optional recording function, greatly providing work efficiency.

Main Functions

1.400-480/450-520/136-174MHz

2.Support Digital/Analog Mode

3.Digital Voice Encryption

4.Private/Group/All Call

5.Kill/Activate

6.Power Save Function

7.High/Low Power Switchable

8.CTCSS/DCS

9.Tail Elimination

10.Monitor

11.Time-Out Time

12.Text Messaging

Technical Specification

GENERAL
Frequency Range	UHF:400-480/450-520MHz VHF:136-174MHz
RF Output Power	H:≤5W L:≤1W
Channels	128
Modulation Distortion	≤5%
Channel Spacing	12.5KHz
Antenna Impedence	50Ω
Operating Temperature	-20℃+50℃
Operating Voltage	DC 7.4V
Battery Type	1600mAh
Dimension(Excluding antenna)	118(H)×58(W)×38(D)mm
Weight(Battery,Antenna Including)	About 240g
TRANSMITTER
Output Power	H:≤5W L:≤1W
Analog Modulation	11K&F3E@12.5KHz
Digital Modulation	8K&F1E@12.5KHz
Digital Audio En/Decode	ASELP/DVSI+2C
Spurious Radiation	9KHz-1GHz ≤-36dBm 1GHz-12.75GHz ≤-30dBm
Adjacent Channel Power	≤ -60 dB@12.5KHz
RECEIVER
Reference Sensitivity	≤ -120 dBm@12.5K
Adjacent Channel Selectivity	≥ 60 dB
Inter-modulation	≥ 60 dB
Co-channel Rejection	≥ -12 dB
Rated Output Power	≤1000mW @16Ω
Spurious Radiation	9KHz-1GHz≤-57dBm 1GHz-12.75GHz≤-47dBm
