5watt Handheld Repeater Digital Two Way Radio

DMR Communication Handheld Two Way Radio

UHF MOTOTRBO SMS DMR Tier Ⅰ&Ⅱ standard handheld digital radio

Brand:
HYDX
Item NO.:
D270
Order(MOQ):
500
Goods Stock:
1
Payment:
T/T,L/C,Credit Card,PayPal,Western Union,Cas
Product Origin:
China
Color:
Black
Shipping Port:
Xiamen/Shenzhen
Lead Time：
45~60
Weight：
270

Inquiry now

Product Detail

Product Description：

·Compact, lightweight design Makes it easy to handle and use Built-in simple voice scrambling Increase the privacy of your conversations VOX capable.

·Multi-channel capability 16 channels to support communication among all of your employees X-Pand technology Provides crisp, clear and strong audio quality even in noisy environments Adjustable power levels Adjustable high and low power levels help extend battery life.

·Repeater capability For use when increased coverage is required.
·Talkaround capability Enables communication even when a repeater is not being used Repeater capability For use when increased coverage is required Talkaround capability Enables communication even when a repeater is not being used.

·Programming cable for easier computer/PC (Microsoft Window 7/8/10 only, No Mac supported) programming, free driver/firmware/programming software available on our website or download at our link, mess of video tutorials on YouTube.

Main Functions

1.400-480/450-520/136-174MHz

2.High/Low Power Switchable 5W/1W

3.High Battery Capacity 1600mAh

4.Monitor

5.Tail Elimination

6.Lone Worker

7.Message

8.Repeater

9.Talk Around

10.Normal/High SQL

11.Battery Indicator

12.Encryption

13.Power Save

14.Channel Scanning/Priority Scanning

Technical Specification

GENERAL
Frequency Range	VHF:136-174MHz UHF:400-480/450-520MHz
RF Output Power	H:≤5W L:≤1W
Channels	16 Channels / 250 Zone
Channel Spacing	12.5KHz
CTCSS/DCS	50 CTCSS / 105 DCS
Antenna Impedence	50Ω
Operating Temperature	-30℃+60℃
Operating Voltage	DC 7.4V
Battery Type	1600mAh
Dimension(Excluding antenna)	133(H)×61(W)×40(D)mm
Weight(Battery,Antenna Including)	About 270g
TRANSMITTER
Output Power	H:≤5W L:≤1W
Frequency Stability	+/-1.5ppm
4FSK Modulation	12.5KHz(date only):7K60FXD 12.5KHz(date+voice):7K60FXE
Free Time Slot Power	≤ -57 dBm
Modulation Distortion	≤ 3%
Digital Audio Encode & Decode	AMBE+2TM
RECEIVER
Analog Sensitivity	0.35uV/-116dBm(20dB SINAD) 0.22uV/-120dBm(Typical)
Digital Selectivity	0.3uV/-117.4dBm(BER5%) 0.7uV/-110dBm(BER1%)
Adjacent Channel Selectivity	TIA603C:60dB@12.5KHz ETSI:60dB@12.5KHz
Inter-modulation	TIA603C:65dB ETSI:65dB
Block	≤ -84 dB
Spurious Response Anti-Interference	TIA603C:70dB ETSI:70dB
Rated Output Power	1000mW
Rated Audio Distortion	≤ 3%
